Rockchip RK3588S 8-
core 64-bit processor
Main frequency up to
2.4GHz
4GB/8GB/16GB
（LPDDR4/4X）
Support 8K video codec

Rockchip RK3588S octa-core 64-bit processor
Main frequency up to 2.4GHz
4GB/8GB/16GB(LPDDR4/4X)
Support 8K video codec

Wi-Fi6
BT5.3，with BLE support
32GB/64GB/128GB/256GB eMMC
USB2.0/3.0
HDMI 2.1
Gigabit LAN port
TF card slot
Type-C power supply

Orange Pi 5B,
the upgrade of Orange Pi 5

Orange Pi 5B adds wireless communication function Wi-Fi6 + BT5.3 module to Orange Pi 5. Wi-Fi supports 2T2R 802.11 ax/ac/a/b/g/n, using both 2.4GHz and 5GHz bands with MIMO standard.Wi-Fi using 2 antennas, 1 of which is shared with BT, using the PCIe 2.1 interface; BT5.3 uses UART/ PCM interface. Meanwhile, 32GB/64GB/128GB/256GB eMMC memory can be added to the Orange Pi 5.

Added Wi-Fi6

Added BT5.3 with BLE support

Added 32GB/64GB/128GB/256GB eMMC memory

Double the performance and drop the price dramatically!

RK3588S 8-core 64-bit processor + Orangepi OS

Orange Pi 5B uses Rockchip RK3588S new generation 8-core 64-bit processor, quad-core A76+quad-core A55, with 8nm process design, up to 2.4GHz main frequency, integrated ARM Mali-G610 GPU, embedded high-performance 3D/2D image acceleration module, built-in NPU with 6Tops computing power, with 4GB/8GB/16GB (LPDDR4/4X) and 32GB/64GB/128GB/256GB eMMC, with dual-band Wi-Fi6, BT5.3, and up to 8K display processing capability.
Orange Pi 5B provides abundant interfaces, including HDMI output, GPIO interface, Type-C, Gigabit LAN port, 2*USB2.0, 1*USB3.0, etc.; It can be widely used in tablets, edge computing, artificial intelligence, cloud computing, AR/VR, intelligent security, smart home and other fields, covering AIoT various industries.
Orange Pi 5B supports Orangepi OS, the official operating system developed by Orange Pi, as well as Android12 and Debian11，Ubuntu22.04，Ubuntu20.04 .

Orange Pi 5B（4GB/8GB/16GB）
VS
Orange Pi 5（4GB/8GB/16GB）

Model	Orange Pi 5B	Orange Pi 5
SOC	Rockchip RK3588S	Rockchip RK3588S
CPU architecture	Cortex-A76+Cortex-A55	Cortex-A76+Cortex-A55
CPU frequency	2.4GHz+1.8GHz	2.4GHz+1.8GHz
Core	8	8
RAM+ Memory	4GB/8GB/16GB （LPDDR4/4X） 32GB/64GB/128GB/256GB eMMC Flash	4GB/8GB/16GB（LPDDR4/4X） 16MB SPI Flash
WiFi+BT	Dual-band Wi-Fi6+BT5.3，with BLE support	-
Ethernet	• YT8531C • Support Gigabit Ethernet	• YT8531C • Support Gigabit Ethernet
USB	2 * USB2.0 +1 * USB3.0 +1 * USB3.1 Type-C	2 * USB2.0 +1 * USB3.0 +1 * USB3.1 Type-C
Audio and video	Support	Support
Camera	3	3
M.2 M-Key socket expansion slot	-	Yes
Debugging	3pin	3pin
Expansion Port	26PIN	26PIN
LCD interface	2	2
Power Source	TYPE-C 5V/4A	TYPE-C 5V/4A
PMU	Yes	Yes
OS	Orangepi OS（Droid）、Orangepi OS（Arch）、Orangepi OS（OH）、Debian11、Ubuntu22.04、Ubuntu20.04、Android12	Orangepi OS（Droid）、Orangepi OS（Arch）、Orangepi OS（OH）、Debian11、Ubuntu22.04、Ubuntu20.04、Android12
PCB Size	62 * 100mm	62 * 100mm

Model
Orange Pi 5B	Orange Pi 5
SOC
Rockchip RK3588S	Rockchip RK3588S
CPU architecture
Cortex-A76+Cortex-A55	Cortex-A76+Cortex-A55
CPU frequency
2.4GHz+1.8GHz	2.4GHz+1.8GHz
Core
8	8
RAM+ Memory
4GB/8GB/16GB（LPDDR4/4X） 32GB/64GB/128GB/256GB eMMC Flash	4GB/8GB/16GB（LPDDR4/4X） 16MB SPI Flash
WiFi+BT
Dual-band Wi-Fi6+BT5.3，with BLE support	-
Ethernet
• YT8531C • Support Gigabit Ethernet	• YT8531C • Support Gigabit Ethernet
USB
2 * USB2.0 +1 USB3.1 +1 USB3.1 Type-C	2 * USB2.0 +1 * USB3.0 +1 * USB3.1 Type-C
Audio and video
Support	Support
Camera
3	3
M.2 M-Key socket expansion slot
-	Yes
Debugging
3pin	3pin
Expansion Port
26PIN	26PIN
LCD interface
2	2
Power Source
TYPE-C 5V/4A	TYPE-C 5V/4A
PMU
Yes	Yes
OS
Orangepi OS（Droid）、Orangepi OS（Arch）、Orangepi OS（OH）、Debian11、Ubuntu22.04、Ubuntu20.04、Android12	Orangepi OS（Droid）、Orangepi OS（Arch）、Orangepi OS（OH）、Debian11、Ubuntu22.04、Ubuntu20.04、Android12
PCB Size
62 * 100mm	62 * 100mm

Rockchip RK3588S
A new generation AIoT chip

Using 8nm LP process, it is faster and consumes less power, bringing superior performance to various AI application scenarios.

CPU8-core 64 core architecture, 4*Cortex-A76 + 4*Cortex-A55

4X
Improvement

RK3588S

RK3399

GPUARM Mali-G610

8X
Improvement

RK3588S

RK3399

NPU6Tops AI computing power

Support INT4/INT8/INT16 hybrid computing, empowering various AI scenarios

Wireless Wi-Fi6+ BT5.3 with BLE support

Built-in 2.4G/5G dual-band Wi-Fi6 and Bluetooth 5.3, supporting BLE, stronger and more stable signal, more convenient and faster network transmission.

Up to 256GB eMMC built-in

Built-in 32GB/64GB/128GB/256GB eMMC for more stable and reliable long-time operation.

Gigabit Ethernet

On-board 1000Mbps Ethernet for stronger and more stable network connection and higher transmission speed.

Rich interfaces, easy to expand

Gathering all kinds of popular interfaces such as MIPI D-PHY, MIPI CSI, USB3.0, USB2.0, Type-C, HDMI2.1, Gigabit Ethernet, etc.

8K video codec for clearer images

Up to support 8K@60fps, the powerful video codec allows for clearer images and more detailed picture quality.

Multi-channel input and output

Support HDMI 2.1 8K video output, USB-C (DP1.4), dual MIPI D-PHY video output for multi-screen display, support three MIPI interface camera inputs.

Supports Orange Pi OS

With its self-designed Launcher, it provides users with the same operating habits as a regular computer to the maximum extent. the installation of Google Store allows users to run Facebook, Instagram, Twitter, YouTube, Telegram and other applications smoothly.

Wide range of application scenarios

It can be widely applied to tablets, edge computing, artificial intelligence, cloud computing, AR/VR, intelligent security, smart home and other fields, covering AIoT various industries.

Artificial intelligence

Tablets

Edge computing

Cloud computing

AR/VR

Intelligent security

Smart home and other fields

Orange Pi 5B（4GB/8GB/16GB） v1.0 Pin Definition

Product parameter

SoC	Rockchip RK3588S (8nm LP process)
CPU	• 8-core 64-bit processor • Big.Little Architecture: 4 * Cortex-A76 and 4 * Cortex-A55, Big core cluster is 2.4GHz, and Little core cluster is 1.8GHz frequency.
GPU	• Arm Mali-G610 MP4 • Compatible with OpenGL ES1.1/2.0/3.2, OpenCL 2.2 and Vulkan 1.2 • 3D graphics engine and 2D graphics engine
NPU	Built-in AI accelerator NPU with up to 6 TOPS, supports INT4/INT8/INT16 mixed operation
PMU	RK806-1
RAM	4GB/8GB/16GB（LPDDR4/4X）
Memory	• 32GB/64GB/128GB/256GB eMMC • MicroSD (TF) Card Slot
USB	USB3.1 * 1 USB2.0 * 2 Type-C (USB3.1) * 1
Video Output	• HDMI2.1, up to 8K@60Hz • DP1.4 (DisplayPort), maximum output resolution up to 8K@30Hz • 2 * MIPI D-PHY TX 4Lane, configurable up to 4K @60Hz
Camera	• MIPI CSI 4Lane • 2 * MIPI D-PHY RX 4Lane
Audio	CODEC: ES8388 • 3.5mm headphone jack audio input/output • Input: Onboard MIC • HDMI 2.1 eARC
Ethernet	10/100/1000Mbps Ethernet
Expansion Port	For extending UART, PWM, I2C, SPI, CAN and GPIO interfaces
Wi-Fi, BT module	On-board Wi-Fi6+BT 5.3 module, Wi-Fi6 interface: PCIe, BT interface: PCM+UART
Button	1 * MaskROM key 1 * Recovery key 1 * On/Off key
Power Source	Support Type-C power supply, 5V@4A
LED	Power indicator: red Status indicator: green
Debugging	3 Pin debug serial port (UART)
Supported OS	Orangepi OS（Droid）、Orangepi OS（Arch）、Debian11、Ubuntu22.04、Ubuntu20.04、Android12

Appearance specification introduction

Dimension	62mm * 100mm
Weight	52g

Product display

Top View

Bottom View
