OrangePi CM5 base board is an official OrangePi base board that can be used with Orange Pi CM5 core board. It has two 2.5G high-speed LAN ports, one Gigabit LAN port, four camera ports, and standard CM5 connectors, and can be used as a CM5 development system as well as embedded boards to be integrated into end-products.
Product display
Top View
Bottom View
OrangePi CM5
Compact and Powerful Industrial PC
OrangePi CM5 is powered by the Rockchip RK3588S 8-core 64-bit processor with 4 Cortex-A76 (2.4GHz) and 4 Cortex-A55 (1.8GHz).
More info
Hardware Parameters
| Board-to-board connector | 3*100pin, 0.4mm pin Pitch, connector model: df40c-100ds-0.4v |
| Memory | MicroSD (TF) card |
| USB | • 1*USB3.0(Host or Device mode supported) • 1*USB2.0 |
| Video output | HDMI 2.1 with up to 8K @60Hz support |
| Camera | 4*MIPI 2-lane |
| Ethernet PHY | • 1*10/100/1000M(YT8531C) • 2*2.5G(RTL8125BG) |
| Infrared receiver | Remote infrared receiver |
| ADC | Reserved for two 12Bit ADC inputs, maximum 1.8V inputs |
| RTC | 2pin connector with 1.25mm pitch |
| FAN | Connect DC 5V fan, 2pin vertical socket, Pitch:1.25mm |
| Expansion port | • 12pin FPC socket • Supports 3.3V 500mA power output • Configurable UART, PWM, I2C, SPI, CAN, GPIO and other functional interfaces |
| Button | Power on/off key, MASKROM key, user-defined key, reset key |
| Power supply | Type-C,5V @ 5A |
| LED | 1* red (POWER), 3* green (WAN, LAN1, LAN2) |
| Debugging | 3pin debug serial port (UART) |
| Supported OS | Orangepi OS（Droid）、Orangepi OS（Arch）、Ubuntu、Debian、Android12 |
| PCB | Length: 90mm, width: 66mm, thickness: 1.6mm |
| Weight | 57.5g |
Note：Due to real-time changes in product batches and production supply factors, the product information and specifications of the above products are subject to change, please refer to the actual product sold in the store on that day.
